ABS Module Lab

Infiniti · repair from $499

Infiniti ABS module repair

Every Infiniti line we've mapped — 3 vehicle lines from 2004–2019 and 14 sourced part numbers — with the ABS unit each one uses. Repair your own module from $499; it comes back with your VIN and coding, no dealer programming.

An ABS hydraulic block with a row of brake-line fittings in a dark sedan's engine bay, in a parking structure under amber light (illustration for Infiniti ABS module repair)
Some Infiniti models share their ABS unit with twins sold under another make — those lines are listed under the make the source used, and they are the same job on our bench.

Model not listed? We repair Infiniti ABS modules beyond this list — start an any-make repair or send us the label.

ABS units in Infiniti vehicles

Grouped the way we price and bench them. Each family page lists every vehicle in it, across makes.

New Infiniti ABS units vs. repair

What a new unit costs online — the part alone, as of October 2026 — next to repairing the one you own from $499.

Known Infiniti ABS failures

What the sources report for these models, before anything else is replaced.

  • 2015-2019 Nissan Murano (Z52) 2015-2018

    NHTSA recalls 18V-601 / 19V-807: the ABS actuator pump seal may leak brake fluid onto the control circuit board, causing a malfunction and possibly an electrical short and fire; ABS lamp stays on. Remedy: dealer replaces the ABS actuator. source ↗

Reading a Infiniti ABS part number

Nissan / Infiniti

47660-xxxxx = 'Actuator Assy-Anti Skid' or 'Anti Skid Actuator & ECU Assembly' (ABS/VDC actuator; Nissan lookup code 47600). Second block is 5 alphanumerics, often model code + revision letter (JA32A, JM21C, 9HR0C, ZR31B, 1NC4E). source ↗

e.g. 47660-JA32A · 47660-JM21C · 47660-9HR0C

Safety recalls to check first

  • 2015-2019 Nissan Murano (Z52) 2015-2018: NHTSA recalls 18V-601 / 19V-807: the ABS actuator pump seal may leak brake fluid onto the control circuit board, causing a malfunction and possibly an electrical short and fire; ABS lamp stays on. Remedy: dealer replaces the ABS actuator. source ↗

ABS codes seen on Infiniti models

  • C1109 — Power and ground system (power supply or ground of the ABS control unit)
  • C1111 — ABS pump motor
  • C1130 — Engine signal - the ABS control unit does not recognise an output signal from the ECM; diagnose and clear the engine (P) codes first. Applies to the 2012-2013 G37 sedan, coupe and convertible (V36).
  • C1140 — ABS actuator relay
  • C1110 — Controller failure - internal malfunction in the ABS actuator and electric unit (control unit)
  • C1120 — ABS inlet (IN) valve system - C1120, C1122, C1124 and C1126 are the inlet-valve codes

Infiniti ABS module questions

Which Infiniti ABS modules do you repair?

This page lists 3 Infiniti vehicle lines from 2004–2019, built around 1 ABS unit family. Models outside the list are taken too — order the any-make repair and we identify the unit from the label.

How much is Infiniti ABS module repair?

Repair of your own module starts at $499; a replacement unit with your data cloned starts at $950. The new-unit prices we could source for Infiniti models are listed on this page with their sources. Return shipping starts at $29.95; the label to us is prepaid.

Where is the part number on a Infiniti ABS module?

On the label of the electronic module itself. 47660-xxxxx = 'Actuator Assy-Anti Skid' or 'Anti Skid Actuator & ECU Assembly' (ABS/VDC actuator; Nissan lookup code 47600).

Are there ABS recalls on Infiniti vehicles?

NHTSA lists a recall on the ABS unit of 1 Infiniti vehicle line (named below). Check your VIN at nhtsa.gov/recalls before sending a module in — an open recall is repaired free by the dealer.

The lab

ABS Module Lab

1168 W Pioneer Parkway
Arlington, TX 76013

View on Google Maps

Mail-in only — ship your module to the address in your order e-mail, not to the bench.

ABS light on? Fix the module you already own.

Look up your part number and order online — we email you a prepaid label to our lab. Or send us a photo of the label and your VIN first, and we'll tell you what you have and what it costs.

Back with your VIN and coding · can’t be repaired? repair price back, minus shipping and a $150 bench evaluation fee · 1-year warranty · rush 2–3 days +$100

Call (817) 505-4201 · 📱 Text us a photo of the module label · Confirm my module first — free · Email repairs@absmodulelab.com
