ABS fault codes — is it your module, or something cheaper?
Manufacturers reuse code numbers with different meanings, so each code here lists what it means on the vehicles that set it, with the page it came from. A code tells you where to look — not always that the module is bad. If the code keeps coming back after the basic checks, we repair the module from $325 — or send us the code and a label photo and we tell you first.

171 codes, grouped by what they point at
Each group is one kind of fault — a wheel-speed circuit, the pump motor, a valve, the module itself — with a one-line answer to whether the module is the likely cause. Open a code for its meaning on each vehicle, the checks to do first and the repair price for those units. Codes listed for one or two vehicle lines are here for completeness; the vehicle page carries the same fact.
Wheel-speed sensor circuit
An open, short or missing signal on one wheel’s speed-sensor circuit. 11 codes across 13 vehicle lines · module sometimes the cause.
- C00355 vehicle linesLeft front wheel speed sensor fault
- C00405 vehicle linesRight front wheel speed sensor fault
- C00455 vehicle linesLeft rear wheel speed sensor fault
- C00505 vehicle linesRight rear wheel speed sensor fault
- C11455 vehicle linesRight front wheel speed sensor input circuit failure
- C11552 vehicle linesLeft front wheel speed sensor input circuit failure
- C02101 vehicle lineRight rear wheel speed sensor circuit (C0215 = left rear)
- C100A1 vehicle lineABS wheel speed sensor fault
- C10201 vehicle lineWheel speed sensor fault
- C11001 vehicle lineLeft-front wheel speed sensor L6/1: line monitoring (circuit fault); C1110 / C1120 / C1130 are the right-front, left-rear and right-rear equivalents
- C11751 vehicle lineLeft rear wheel speed sensor input circuit failure
Wheel-speed signal implausible or erratic
A wheel-speed signal that drops out, disagrees with the other wheels or is read as implausible. 7 codes across 5 vehicle lines · module rarely the cause.
- C12332 vehicle linesLeft-front wheel speed sensor signal missing: air gap too large, reluctor damage, high-resistance signal circuit, or sensor failure
- 002831 vehicle lineL/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
- 002851 vehicle lineL/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
- 002871 vehicle lineL/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
- 002901 vehicle lineL/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
- C12221 vehicle lineWheel speed signal conflict: punctured tyre, mismatched wheel/tyre sizes, or damaged reluctor teeth
- C12381 vehicle lineForeign matter on the tip of the right rear speed sensor (C1239 = left rear)
Pump motor, motor relay or relay circuit
The ABS pump motor, the relay that feeds it, or a pump that runs when it should not. 35 codes across 81 vehicle lines · module often the cause.
- C211212 vehicle linesSensor supply 1 voltage circuit high
- C027311 vehicle linesOpen circuit in the ABS motor relay circuit (the relay that supplies power to the ABS pump motor); C0274 is a B+ short in the same circuit
- C027811 vehicle linesOpen circuit in the ABS solenoid relay circuit (the relay that supplies power to the ABS solenoids); C0279 is a short in the same circuit
- C211611 vehicle linesABS Pump Motor Supply Low Voltage
- C109510 vehicle linesABS hydraulic pump motor failure
- C111110 vehicle linesABS pump motor
- C114010 vehicle linesABS actuator relay
- C24028 vehicle linesPump motor failure: motor relay or fuse open, open or short in the motor, or motor lock
- C02657 vehicle linesEBCM relay circuit fault
- 012764 vehicle linesHydraulic Pump Outside Tolerance
- C11854 vehicle linesOpen internal power relay
- C12524 vehicle linesBrake booster pump motor failure
- C12534 vehicle linesBrake booster pump relay failure
- C12564 vehicle linesAccumulator low pressure
- C00203 vehicle linesABS pump motor control
- C01103 vehicle linesPump Motor Circuit Malfunction
- C02013 vehicle linesAnti-Lock Brake System Enable Relay Contact Circuit
- 5DF02 vehicle linesHydraulic Pump Motor; pump motor failure
- 5DF12 vehicle linesHydraulic Pump Motor; hydraulic unit - motor connection failure
- BCM-00702 vehicle linesPump Motor Faulty Signal
- BCM-C00201C2 vehicle linesABS Pump Motor Control: General Electrical Failures - Circuit Voltage Out of Range (also listed as 'Pump Motor Defect')
- C13002 vehicle linesPump Motor won't run or won't stop running
- 12761 vehicle linePSM/ABS hydraulic pump electrical fault; moisture entering the harness connector at the PSM hydraulic unit is a known cause
- 42661 vehicle lineReturn pump fault (ABS/PSM)
- C01211 vehicle lineValve Relay Circuit (Malfunction)
- C02001 vehicle linePump motor
- C02671 vehicle linePump Motor Circuit
- C02681 vehicle linePump Motor Circuit
- C1022-141 vehicle linePower source failure for pump motor; possible causes: open, short or poor connection on the +B ABS/VSA motor line, blown fuse A3-3, or VSA modulator-control unit internal failure
- C10731 vehicle linePump motor control circuit
- C13101 vehicle lineCheck power supply of the high-pressure and return pump A7/3m1
- C21311 vehicle lineAccumulator / pressure reservoir fault
- C22161 vehicle lineABS Pump Motor Supply Low Voltage
- C26BB1 vehicle lineHydraulic malfunction in pressure supply
- C26DE1 vehicle lineHydraulic malfunction in pressure supply
Valve or solenoid circuit
One of the solenoid valves inside the hydraulic unit, or the circuit that drives it. 25 codes across 37 vehicle lines · module often the cause.
- C022611 vehicle linesSFR solenoid circuit - open or short in the SFRH or SFRR solenoid circuit of the ABS actuator; C0236, C0246 and C0256 are the SFL, SRR and SRL solenoid circuits
- C11209 vehicle linesABS inlet (IN) valve system - C1120, C1122, C1124 and C1126 are the inlet-valve codes
- 123-114 vehicle linesVSA solenoid valve malfunction
- 38-114 vehicle linesABS solenoid valve malfunction
- C12673 vehicle linesDSC module anti-lock functions temporarily disabled (module failure); attempt a hard reset before replacing the module
- 014182 vehicle linesSwitch valve 1
- 014212 vehicle linesHigh pressure valve 2
- C11212 vehicle linesABS outlet (OUT) valve system - C1121, C1123, C1125 and C1127 are the outlet-valve codes
- 121 to 1241 vehicle lineVSA regulator or suction valve solenoid coil open or short (121/122 right front, 123/124 left front)
- 121-11 to 124-111 vehicle lineVSA solenoid valve malfunctions
- 31 to 381 vehicle lineInlet or outlet valve solenoid coil open or short (31/32 right front, 33/34 left front, 35/36 right rear, 37/38 left rear)
- 32-11 to 38-111 vehicle lineABS solenoid valve malfunctions
- BCM-00741 vehicle lineHydraulic Valve Faulty Signal
- BCM-01391 vehicle linePre-pressure Valve Power Brake Booster Signal Outside its Permitted Range
- C0001:011 vehicle lineTCS control channel A valve 1
- C0002:011 vehicle lineTCS control channel A valve 2
- C00101 vehicle lineLeft front inlet (valve) control
- C0010-491 vehicle lineInlet solenoid (left front) circuit failure; possible cause: VSA modulator-control unit internal failure
- C1020-491 vehicle lineVSA master cut valve failure (unexpected operation); possible cause: VSA modulator-control unit internal failure
- C11941 vehicle lineFront left dump valve malfunction (C1194/C1195)
- C11981 vehicle lineFront left isolation valve malfunction (C1198/C1200)
- C12021 vehicle lineRear dump valve malfunction (C1202/C1204)
- C12061 vehicle lineIsolation Valve, Front (C1206/C1208)
- C12661 vehicle lineModulator solenoids power supply circuit fault (open circuit, short circuit, high resistance) or modulator failure
- C46B0001 vehicle lineThe power supply to the solenoid valve is faulty
Control module internal fault
The module reports a fault in its own electronics: processor, memory, drivers or internal connections. 26 codes across 58 vehicle lines · module often the cause.
- C220014 vehicle linesAnti-Lock Brake Module Internal Failure
- C2200-4912 vehicle linesABS Module has detected an internal electronic error
- C11109 vehicle linesController failure - internal malfunction in the ABS actuator and electric unit (control unit)
- B13428 vehicle linesECU internal fault
- C16047 vehicle linesECU hardware error: the HECU detects a fault in its own IC components (memory, register, A/D converter)
- U3000:497 vehicle linesControl module fault
- U3000:416 vehicle linesControl module fault
- 163524 vehicle linesControl Module Faulty: Electrical Error - internal failure within the ABS unit (ATE MK61)
- C05504 vehicle linesElectronic Control Unit Performance
- C056D3 vehicle linesControl unit internal fault
- C11373 vehicle linesDSC module malfunction (module failure); also turns on the check-engine light
- 50011 vehicle lineInternal fault in component N30/4 (Electronic Stability Program control unit)
- 59051 vehicle lineControl unit N47-5 (ESP control unit), internal fault
- 59061 vehicle lineControl unit N47-5 (ESP control unit), internal fault
- 59441 vehicle lineInternal fault in component N30/4 (Electronic Stability Program control unit)
- 59451 vehicle lineInternal fault in component N30/4 (Electronic Stability Program control unit)
- 81-11 vehicle lineVSA modulator-control unit internal circuit malfunction (Honda Service Bulletin 16-005, 2011-2015 Odyssey)
- BCM-00521 vehicle lineControl Module Internal Fault
- C10001 vehicle lineControl unit N47-5 (ESP and BAS control module) is defective (C1000 through C1013 all carry this text)
- C10011 vehicle lineInternal fault in component N30/4 (ESP control unit)
- C14BE1 vehicle lineSystem fault in control module A7/3n1 (SBC control module)
- C19451 vehicle lineInternal fault in component N30/4 (ESP control unit)
- C2200-461 vehicle lineCalibration/Parameter Memory Failure - it CANNOT fix this on MK60E units
- C226F1 vehicle lineSBC control unit internal fault
- C22EF1 vehicle lineSBC control unit internal fault
- U0416-681 vehicle lineVSA system malfunction; possible cause: VSA modulator-control unit internal failure
Communication — no response from the ABS module
Other modules cannot talk to the ABS module, or it is missing from the vehicle network. 14 codes across 44 vehicle lines · module often the cause.
- U012115 vehicle linesLost Communication With Anti-Lock Brake System (ABS) Control Module
- C113010 vehicle linesEngine signal - the ABS control unit does not recognise an output signal from the ECM; diagnose and clear the engine (P) codes first. Applies to the 2012-2013 G37 sedan, coupe and convertible (V36).
- C16118 vehicle linesCAN time-out ECM: no engine control module message reaches the HECU within 500 ms; ESC control is switched off, ABS/EBD stay active
- 01316:0133 vehicle linesABS Control Module: No Signal/Communication
- 5DF52 vehicle linesNo communication / internal fault
- 86-142 vehicle linesF-CAN communication with gauge control module malfunction
- C16052 vehicle linesCAN hardware error: the HECU detects a CAN RAM malfunction
- U1017002 vehicle linesABS Control Module Communication
- BCM-01081 vehicle lineCommunication Fault Between Control Units
- C24DB1 vehicle lineCAN communication fault - typically mismatched part numbers after a unit swap
- P20361 vehicle lineNo or incorrect message from control unit N47-5 (ESP control unit) - logged in other modules when the ESP unit fails
- U00731 vehicle lineNo communication (control module communication bus off)
- U01551 vehicle lineLost communication with gauge control module
- U04151 vehicle lineInvalid data from the ABS module
Supply voltage to the module
Battery or ignition voltage at the ABS module reads too low or too high. 13 codes across 41 vehicle lines · module sometimes the cause.
- C124115 vehicle linesLow or high power supply voltage to the brake control ECU
- C110910 vehicle linesPower and ground system (power supply or ground of the ABS control unit)
- C21006 vehicle linesBattery (supply) voltage low
- C21016 vehicle linesBattery voltage high
- 006682 vehicle linesSupply Voltage Terminal 30: Implausible Signal
- C11022 vehicle linesBattery voltage low at the HECU
- 61-11 vehicle lineVSA modulator-control unit power source circuit (IG) low voltage (Honda SB 16-005)
- B16761 vehicle lineABS/TC module supply voltage out of range: system switches off above 19 V and is inhibited below 9 V
- BCM-00581 vehicle linePower Supply Voltage too High
- C12101 vehicle lineTerminal 30 (battery feed) undervoltage
- C15501 vehicle lineCheck power supply at control unit N47-5 (ESP and BAS control module)
- C20001 vehicle lineSupply voltage of control unit N30/4 too low (undervoltage)
- U3006-161 vehicle linePower source failure for ECU (low voltage); possible causes: loose or poor connections at the VSA modulator-control unit terminals, low 12 V battery voltage
Stability-control sensors and calibration
Steering-angle, yaw-rate or acceleration sensor signals, or a calibration that was never done. 2 codes across 2 vehicle lines · module sometimes the cause.
Brake-pedal switch or brake-pressure sensor
The brake-light switch signal or the brake-pressure sensor the module reads. 10 codes across 9 vehicle lines · module sometimes the cause.
- 5E202 vehicle linesHydraulic pressure sensor internal (brake pressure sensor inside the MK60 hydraulic unit; DSC lights stay on, DSC button unresponsive)
- C14402 vehicle linesBrake pressure transducer malfunction
- 44601 vehicle linePressure sensor (ABS/PSM)
- 66-111 vehicle linePressure sensor issues
- 66-131 vehicle linePressure sensor issues
- BCM-01361 vehicle lineBrake Pressure Sensor 1 & 2 Outside Permitted Range
- BCM-01501 vehicle lineStop Lamp Switch Signal Outside its Permitted Range
- C0044-491 vehicle lineMaster cylinder pressure sensor failure (internal circuit failure); possible cause: VSA modulator-control unit internal failure
- C121E1 vehicle lineBrake Pressure Transmitter
- C12881 vehicle lineBrake pressure transducer malfunction
Maker-specific flash and group codes
A maker’s own code number — Honda/Acura two- and three-digit codes, VW/Audi five-digit group codes — with its own meaning per make. 6 codes across 9 vehicle lines · module sometimes the cause.
- 011305 vehicle linesABS Operation: Implausible Signal
- 85-013 vehicle linesProblem in VSA system
- 59-11 vehicle lineStored with an intermittent VSA indicator or trailer stability assist warning (or a shift lever that will not leave Park)
- 66-11 vehicle lineStored with an intermittent VSA indicator or trailer stability assist warning (or a shift lever that will not leave Park)
- 67-11 vehicle lineStored with an intermittent VSA indicator or trailer stability assist warning (or a shift lever that will not leave Park)
- 69-11 vehicle lineStored with an intermittent VSA indicator or trailer stability assist warning (or a shift lever that will not leave Park)
Other system-level codes
A code outside the common ABS circuit families: configuration, coding, wear counters, hydraulic conditions or codes set because of another system. 22 codes across 25 vehicle lines · module sometimes the cause.
- C120114 vehicle linesEngine control system malfunction
- C122314 vehicle linesABS control system malfunction
- BCM-00712 vehicle linesIndividual meanings not given
- BCM-00722 vehicle linesIndividual meanings not given
- BCM-C0020012 vehicle linesIndividual meanings not given
- BCM-C0020712 vehicle linesIndividual meanings not given
- C13912 vehicle linesBrake actuator internal fluid leak condition (with C1252/C1253/C1256) per Toyota T-SB-0032-16, which applies to 2006-2007 Highlander HV
- BCM-E0031 vehicle lineConfiguration Fault (faulty configuration)
- C0077-781 vehicle lineLow tire pressure threshold refinement: stored by the VSA modulator-control unit with the Low Tire Pressure indicator on although tire pressures are set correctly (2015 CR-V)
- C055F-001 vehicle lineABS Hydraulic Unit Performance - FCA TSB 08-032-22 Rev. A (2021 JL 4xe 2.0L PHEV, sales code ECX); software flash corrects a stored fault, active fault follows normal diagnostics
- C123EF01 vehicle lineHydraulic Brake Booster Limit Value Reached
- C14011 vehicle line'You may have a C1401 code regardless of which rebuild tier your module requires' (meaning not given on the page)
- C16001 vehicle lineControl unit N47-5 (ESP, PML and BAS control unit): coding is faulty
- C19631 vehicle lineStability Control Inhibit Warning
- C2206-001 vehicle lineVehicle Configuration Mismatch - FCA TSB 08-099-23 (2021-2022 JL 4xe 2.0L PHEV, sales code ECX): can set after re-gearing past 4.5:1; fixed by ABS software flash
- C235A1 vehicle linePump wear threshold reached (pump cycles)
- C235C1 vehicle lineValve actuation wear threshold reached
- C235D1 vehicle lineLifetime counter exceeded
- C24981 vehicle lineService threshold reached (often alongside C249F)
- C249F1 vehicle lineSBC service-life counter expired (about 300,000 brake actuations); resetting the counter only hides the wear
- P20681 vehicle lineElectronic transmission ECU N15
- P20CC1 vehicle lineRough road detection
ABS light on? Fix the module you already own.
Look up your part number and order online — we email you a prepaid label to our lab. Or send us a photo of the label and your VIN first, and we'll tell you what you have and what it costs.
Back with your VIN and coding · can’t be repaired? repair price back, minus shipping and a $150 bench evaluation fee · 1-year warranty · rush 2–3 days +$100
Call (817) 505-4201 · 📱 Text us a photo of the module label · Confirm my module first — free · Email repairs@absmodulelab.com
