Toyota · 2005-2015 · Toyota actuator
Toyota Tacoma (2nd gen) ABS module repair
Mail in your Toyota Tacoma (2nd gen) ABS module with our prepaid label. It comes back repaired and still coded to your VIN — or, if it is past repair, as a refurbished unit with your data cloned on, or with your repair price refunded minus shipping and a $150 bench evaluation fee.
- Unit: Toyota actuator
- Stability control: yes
- 3 sourced part numbers
- 7 fault codes
Known failure
The ABS module in the Toyota Tacoma (2nd gen)
The 2005-2015 Toyota Tacoma (2nd gen) uses this ABS unit: Brake actuator assembly with integrated skid control ECU. source ↗ It is an ABS unit with stability control, so the module also handles traction and stability functions. source ↗ On our bench that puts it in the Toyota / Lexus brake actuator (ABS / VSC) family, alongside 14 other vehicle lines on this site.
Its ABS module appears under 3 part numbers, starting with 44050-04100 (ACTUATOR Assembly, Brake; 2008-2011 Tacoma Base 2.7 (2TRFE) / 4.0 (1GRFE)). source ↗ Different numbers usually separate model years, drivetrains and option packages — match the number on your own module label rather than the year alone. The pump, valve block and control unit are one assembly. Send us a photo before you pull it and we confirm what to ship and how to cap the ports.
Compare: a new unit
44050-04100 listed online, part only (as of October 2026)
$1,265.60
Repairing the one you own
From $499
Already coded to your VIN · 1-year warranty
Toyota Tacoma (2nd gen) ABS module part numbers
Match the number printed on your module's label. Each number opens its own page — the vehicles it fits, the unit and the price — and parts-catalog sources are linked.
ACTUATOR Assembly, Brake; 2008-2011 Tacoma Base 2.7 (2TRFE) / 4.0 (1GRFE)
ACTUATOR Assembly, Brake; 2010-2012 Tacoma Base 2.7/4.0
ACTUATOR Assembly, Brake; 2012-2016 Tacoma Base/Limited/SR5, note 'TOWING PACKAGE-WITH'
Reading the label · Toyota / Lexus
Five characters, a dash, five more (44050-06070). 44050 is Toyota’s number for the brake actuator assembly — the ABS/VSC hydraulic actuator, usually with the skid-control ECU and pump; 44540 and 44500 numbers are actuator-with-pump variants. source ↗
e.g. 44050-06070 · 44050-0C430 · 44050-42B21
ABS fault codes on the Toyota Tacoma (2nd gen)
- C1241
Low Power Supply Voltage Malfunction - +BS voltage below 9.5 V; trouble areas: ABS NO. 2 fuse, battery, charging system, harness, skid control ECU (brake actuator assembly) source ↗
- C1201
Engine control system malfunction (VSC-equipped trucks) source ↗
- C1223
ABS control system malfunction (VSC-equipped trucks) source ↗
- C1336
Zero point calibration of the acceleration sensor not done (VSC-equipped trucks) source ↗
- C0226
SFR solenoid circuit - open or short in the SFRH or SFRR solenoid circuit of the ABS actuator; C0236, C0246 and C0256 are the SFL, SRR and SRL solenoid circuits
- C0273
Open circuit in the ABS motor relay circuit (the relay that supplies power to the ABS pump motor); C0274 is a B+ short in the same circuit
- C0278
Open circuit in the ABS solenoid relay circuit (the relay that supplies power to the ABS solenoids); C0279 is a short in the same circuit
Our promise
Can’t be repaired? You don’t pay for a repair.
If the bench finds your module past repair, we stop and tell you before doing anything else. Then you choose:
- 1A replacement — a refurbished unit of the same family with your VIN, coding and configuration cloned onto it, from $950. You pay only the difference from what you already paid, and we confirm the amount with you first.
- 2Your module back — with the repair price refunded, minus shipping costs and a $150 bench evaluation fee.
Either way, nothing that changes your price happens without your OK.
Refund stages in our terms →Other vehicles with the Toyota actuator
Same unit family, same bench process and the same starting price.
- 2007-2012 Lexus ES 350 (XV40)
- 2006-2011 Lexus IS 250 / IS 350 (XE20)
- 2004-2009 Lexus RX 330
- 2010-2015 Lexus RX 350
- 2010-2020 Toyota 4Runner (N280)
- 2002-2006 Toyota Camry (XV30)
- 2012-2017 Toyota Camry (XV50, non-hybrid)
- 2009-2013 Toyota Corolla (E140, US)
- 2014-2019 Toyota Corolla (E170, US)
- 2003-2019 Toyota Highlander (XU20, XU40, XU50, gasoline)
Toyota Tacoma (2nd gen) ABS module questions
Which ABS module is in the Toyota Tacoma (2nd gen)?
It uses this unit: Brake actuator assembly with integrated skid control ECU. We price and bench it as part of the Toyota / Lexus brake actuator (ABS / VSC) family. The exact unit is confirmed from your module label on arrival.
How much does ABS module repair cost for a Toyota Tacoma (2nd gen)?
Repair of your own module starts at $499; a replacement unit with your data cloned starts at $950. For comparison, a new part (44050-04100) is listed online at $1,265.60 for the part alone, as of October 2026. Return shipping starts at $29.95 and the label to us is prepaid.
My Toyota Tacoma (2nd gen) module number is not listed. Can you still repair it?
The 3 numbers above are the ones we could source, not every one that exists. Send us a photo of the label first, or order the repair and we confirm the unit before any work.
