ABS Module Lab

Jaguar · 1995-2003 · MK20

Jaguar XK8 / XKR (X100) ABS module repair

Mail in your Jaguar XK8 / XKR (X100) ABS module with our prepaid label. It comes back repaired and still coded to your VIN — or, if it is past repair, as a refurbished unit with your data cloned on, or with your repair price refunded minus shipping and a $150 bench evaluation fee.

  • Unit: MK20
  • Stability control: depends on trim
  • 11 sourced part numbers
  • 6 fault codes

Known failure

All ABS warning lights on and ABS pump not working for the 1995-1997 Jaguar module.

The ABS module in the Jaguar XK8 / XKR (X100)

The 1995-2003 Jaguar XK8 / XKR (X100) uses this ABS unit: Continental Teves (ATE) ATE MK20 (1997-2003); 1995-1997 module type not named. The same unit covers the XK8 / XKR (X100), XJ8 / XJR / Vanden Plas / XJ6 (X308) and XJ6 / XJ12 / XJR / XJS / Vanden Plas 1995-1997 (X300). On our bench that puts it in the ATE / Continental MK20 family, alongside 6 other vehicle lines on this site.

Its ABS module appears under 11 part numbers, starting with LJA2210AH (The page's Jaguar applications are 1997-2003 XK8/XKR/XJ8/XJR/XJ6/Vanden Plas (not mapped per model)). Different numbers usually separate model years, drivetrains and option packages — match the number on your own module label rather than the year alone. The control unit is mounted on the valve block. On many units it unbolts, so the brake lines stay on — send us a photo if you are not sure.

Jaguar XK8 / XKR (X100) ABS module part numbers

Match the number printed on your module's label. Each number opens its own page — the vehicles it fits, the unit and the price — and parts-catalog sources are linked.

Reading the label · ATE / Continental Teves (supplier number, all brands)

Read as 10.0xxx-xxxx.x: control units 10.0960-/10.0961-/10.0926-/10.0948- with '.3', hydraulic units 10.0212-/10.0204-/10.0399- with '.4'. Often run together as 11 digits.

e.g. 10.0960-0818.3 · 10.0961-0820.3 · 10.0212-0044.4

Reading the label · Ford-style number (Jaguar / Land Rover, Ford era)

Prefix (4 chars: year letter/digit + vehicle code) + base + suffix.

e.g. BJ32-2C405-AG · GX53-2C353-AH · EX53-14F447-BC

Reading the label · Jaguar (pre-Ford numbering and later Jaguar numbers)

1995-2003 Jaguar ABS modules: three letters + '2210' + two-letter suffix (LNA/LNC/LNF/LJA/MNA 2210 xx), plus JLM + 5 digits on the 1995-1997 module. Later Jaguar part numbers: C2x / T2x + 4-5 digits (e.g. C2Z28243, T2R22161).

e.g. LNC2210AD · LNA 2210-AA · MNA 2210-AB

ABS fault codes on the Jaguar XK8 / XKR (X100)

  • C1095

    Pump motor failure: pump motor circuit high resistance, open, or shorted to ground or battery voltage, or pump motor failure; the ABS system switches off

  • C1137

    Control module internal circuit failure: module ground or power circuits faulty, or module failure; the system switches off

  • C1145

    Right-front wheel speed sensor circuit electrical failure (sensor or wiring open or shorted, or module failure)

  • C1233

    Left-front wheel speed sensor signal failure: wiring open or shorted, incorrect sensor-to-reluctor air gap, module or solenoid valve failure

  • C1267

    Modulator valve failure: intermittent sensor wiring faults, radio-frequency interference, modulator valve or module failure

  • B1676

    ABS/TC module supply voltage out of range: system switches off above 19 V and is inhibited below 9 V

Our promise

Can’t be repaired? You don’t pay for a repair.

If the bench finds your module past repair, we stop and tell you before doing anything else. Then you choose:

  1. 1A replacement — a refurbished unit of the same family with your VIN, coding and configuration cloned onto it, from $950. You pay only the difference from what you already paid, and we confirm the amount with you first.
  2. 2Your module back — with the repair price refunded, minus shipping costs and a $150 bench evaluation fee.

Either way, nothing that changes your price happens without your OK.

Refund stages in our terms →

Other vehicles with the MK20

Same unit family, same bench process and the same starting price.

All ATE / Continental MK20 vehicles →

Jaguar XK8 / XKR (X100) ABS module questions

Which ABS module is in the Jaguar XK8 / XKR (X100)?

It uses this unit: Continental Teves (ATE) ATE MK20 (1997-2003); 1995-1997 module type not named. We price and bench it as part of the ATE / Continental MK20 family. The exact unit is confirmed from your module label on arrival.

How much does ABS module repair cost for a Jaguar XK8 / XKR (X100)?

Repair of your own module starts at $499; a replacement unit with your data cloned starts at $950. Return shipping starts at $29.95 and the label to us is prepaid.

My Jaguar XK8 / XKR (X100) module number is not listed. Can you still repair it?

The 11 numbers above are the ones we could source, not every one that exists. Send us a photo of the label first, or order the repair and we confirm the unit before any work.
