Volkswagen · repair from $499

Volkswagen ABS module repair

Every Volkswagen line we've mapped — 6 vehicle lines from 1998–2020 and 78 sourced part numbers — with the ABS unit each one uses. Repair your own module from $499; it comes back with your VIN and coding, no dealer programming.

The rain-beaded side mirror and door of a small dark car on a cobbled street at dusk (illustration for Volkswagen ABS module repair)

Model not listed? We repair Volkswagen ABS modules beyond this list — start an any-make repair or send us the label.

ABS units in Volkswagen vehicles

Grouped the way we price and bench them. Each family page lists every vehicle in it, across makes.

Known Volkswagen ABS failures

What the sources report for these models, before anything else is replaced.

  • 1998-2006 Volkswagen Golf / GTI (Mk4, 1J)

    A rebuilder lists the common failures for this module as 'ABS Warning lights are on', 'ABS Pump motor codes' and 'Wheel speed sensor code' (1998-2001 Beetle/Golf/Jetta); its MK60 page adds no communication with the module and a non-working speedometer. source ↗

  • 2006-2018 Volkswagen Golf / Rabbit / GTI / Golf R (Mk5-Mk6)

    A rebuilder: faults relating to the ABS motor, block and pump cause the VW Golf, Audi A3 and TT ABS light to remain on, and 'ABS pump and module failure is caused by internal component breakdown'; a rebuilder ties 16352 on the Golf Mk5 to an internal failure of the ATE MK61 control unit. source ↗

  • 1998-2005 Volkswagen Passat B5 / B5.5 (sedan, wagon, 4Motion, W8)

    A rebuilder lists 'Loss of communication' as the common failure of the pre-programmed Bosch 5.3 module; a rebuilder's 5.3 rebuild targets loss of communication, intermittent functionality and wheel-speed-sensor faults by restoring failed internal connections. source ↗

  • 2009-2020 Volkswagen Tiguan (5N, first generation)

    A rebuilder lists the 2009-2017 Tiguan module's common failures as no communication with the ABS module, all ABS warning lights on, speedometer not working, ABS pump not working and wheel-speed-sensor codes. For MK100 units it describes a hydraulic-block fault where brake calipers stay engaged after the pedal is released. source ↗

  • 2004-2010 Volkswagen Touareg (7L, first generation)

    A rebuilder: the Touareg ABS pump and module fitted 2005-2008 'can be very problematic'; the ABS warning light becomes constantly illuminated with codes such as 01276 (hydraulic pump V64, electrical fault in circuit) and/or 01130 (ABS operation implausible signal). source ↗

Reading a Volkswagen ABS part number

Volkswagen / Audi (VAG OEM)

Prefix (3 chars) + group + base + optional 1-3 letter suffix. Control units: 907 379 (Bosch 5.3: 998 375; some 907 375). Hydraulic units: 614 517 / 614 109 / 614 117 / 614 111, often listed with a 'BEF' (filled) or '-REP' suffix. Printed with spaces, dashes or nothing. source ↗

e.g. 1C0907379K · 1K0-614-517-ED-BEF · 8E0 998 375 G

ATE / Continental Teves (supplier number, all brands)

Read as 10.0xxx-xxxx.x: control units 10.0960-/10.0961-/10.0926-/10.0948- with '.3', hydraulic units 10.0212-/10.0204-/10.0399- with '.4'. Often run together as 11 digits (10021200214 = 10.0212-0021.4 on the same a rebuilder.com page). source ↗

e.g. 10.0960-0818.3 · 10.0961-0820.3 · 10.0212-0044.4

Bosch (supplier number, all brands)

10-digit Bosch number on a white label. Control units 0 265 9xx xxx (5.7: 0 265 950/900 xxx; SBC: 0 265 960 0xx); Bosch 5.3 control units 0 273 004 xxx; 0 265 2xx xxx also seen. a rebuilder writes short forms ('950-080', '358'). source ↗

e.g. 0 265 950 080 · 0265950958 · 0 273 004 358

ABS codes seen on Volkswagen models

  • 01130 — ABS Operation: Implausible Signal (causes include faulty Brake Electronics Control Module J104; clears only after a test drive above 20 km/h)
  • 01276 — ABS Hydraulic Pump (V64): Signal Outside Specifications / Electrical Fault in Circuit / Implausible Signal. a diagnostic-tool maker: on Golf/Jetta/Bora (1J/9M) check the fuse panel on top of the battery for damage.
  • 00283 — L/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
  • 00285 — L/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
  • 00287 — L/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
  • 00290 — L/F, R/F, L/R, R/R Wheel Speed Sensor: Implausible Signal
  • 00668 — Supply Voltage Terminal 30: Implausible Signal
  • 01316:013 — ABS Control Module: No Signal/Communication
  • 16352 — Control Module Faulty: Electrical Error (a rebuilder wording); a rebuilder: internal failure in the ATE MK61 on Golf Mk5 / Audi A3 8P / TT 8N
  • U101700 — ABS Control Module Communication

Volkswagen ABS module questions

Which Volkswagen ABS modules do you repair?

This page lists 6 Volkswagen vehicle lines from 1998–2020, built around 5 ABS unit families. Models outside the list are taken too — order the any-make repair and we identify the unit from the label.

How much is Volkswagen ABS module repair?

Repair of your own module starts at $499; a replacement unit with your data cloned starts at $950. Return shipping starts at $29.95; the label to us is prepaid.

Where is the part number on a Volkswagen ABS module?

On the label of the electronic module itself. Prefix (3 chars) + group + base + optional 1-3 letter suffix.

ABS light on? Fix the module you already own.

Look up your part number and order online — we email you a prepaid label to our lab. Or send us a photo of the label and your VIN first, and we'll tell you what you have and what it costs.

Back with your VIN and coding · can’t be repaired? repair price back, minus shipping · 1-year warranty · rush 2–3 days +$100
