ABS Module Lab
Start Repair

Audi · 2015-2020 · MK100

Audi A3 / S3 (8V) ABS module repair

Mail in your Audi A3 / S3 (8V) ABS module with our prepaid label. It comes back repaired and still coded to your VIN — or, if it is past repair, as a refurbished unit with your data cloned on, or with your repair price refunded minus shipping.

  • Unit: MK100
  • Stability control: depends on trim
  • 7 sourced part numbers

Known failure

No communication with the ABS module, ABS warning lights on, wheel-speed-sensor codes and an electronic parking brake that sticks on or will not engage on one or both sides for the MK100 46-pin module.

The ABS module in the Audi A3 / S3 (8V)

The 2015-2020 Audi A3 / S3 (8V) uses this ABS unit: Continental Teves (ATE) ATE MK100 (46-pin). The same unit covers the A3 / S3 (8V) and TT / TTS / TT RS (8S). On our bench that puts it in the Continental MK100 family, alongside 5 other vehicle lines on this site.

Its ABS module appears under 7 part numbers, starting with 5Q0-907-379-AK-REP (Not mapped per model)). Different numbers usually separate model years, drivetrains and option packages — match the number on your own module label rather than the year alone. The control unit is mounted on the valve block. On many units it unbolts, so the brake lines stay on — send us a photo if you are not sure.

Audi A3 / S3 (8V) ABS module part numbers

Match the number printed on your module's label. Each number links to the page it was found on.

  • 5Q0-907-379-AK-REP

    Not mapped per model)

  • 5Q0-907-375-AA

    Not mapped per model)

  • 5Q0-614-517-AL-BEF

    Not mapped per model)

  • 3Q0-614-517-AB-BEF

    Not mapped per model)

  • 8S0-907-379-J-REP

    Not mapped per model)

  • 8S0-614-517-C-BEF

    Not mapped per model)

  • 8S0-998-375-C

    Not mapped per model)

Reading the label · Volkswagen / Audi (VAG OEM)

Prefix (3 chars) + group + base + optional 1-3 letter suffix. Control units: 907 379 (Bosch 5.3: 998 375; some 907 375). Hydraulic units: 614 517 / 614 109 / 614 117 / 614 111, often listed with a 'BEF' (filled) or '-REP' suffix. Printed with spaces, dashes or nothing.

e.g. 1C0907379K · 1K0-614-517-ED-BEF · 8E0 998 375 G

Reading the label · ATE / Continental Teves (supplier number, all brands)

Read as 10.0xxx-xxxx.x: control units 10.0960-/10.0961-/10.0926-/10.0948- with '.3', hydraulic units 10.0212-/10.0204-/10.0399- with '.4'. Often run together as 11 digits.

e.g. 10.0960-0818.3 · 10.0961-0820.3 · 10.0212-0044.4

Our promise

Can’t be repaired? You don’t pay for a repair.

If the bench finds your module past repair, we stop and tell you before doing anything else. Then you choose:

  1. 1A replacement — a refurbished unit of the same family with your VIN, coding and configuration cloned onto it, from $950. You pay only the difference from what you already paid, and we confirm the amount with you first.
  2. 2Your module back — with the repair price refunded, minus shipping costs.

Either way, nothing that changes your price happens without your OK.

Refund stages in our terms →

Other vehicles with the MK100

Same unit family, same bench process and the same starting price.

All Continental MK100 vehicles →

Audi A3 / S3 (8V) ABS module questions

Which ABS module is in the Audi A3 / S3 (8V)?

It uses this unit: Continental Teves (ATE) ATE MK100 (46-pin). We price and bench it as part of the Continental MK100 family. The exact unit is confirmed from your module label on arrival.

How much does ABS module repair cost for a Audi A3 / S3 (8V)?

Repair of your own module starts at $499; a replacement unit with your data cloned starts at $950. Return shipping starts at $29.95 and the label to us is prepaid.

My Audi A3 / S3 (8V) module number is not listed. Can you still repair it?

The 7 numbers above are the ones we could source, not every one that exists. Send us a photo of the label first, or order the repair and we confirm the unit before any work.

Audi A3 / S3 (8V) ABS light on? Fix the module you already own — from $499.

Look up your part number and order online — we email you a prepaid label to our lab. Or send us a photo of the label and your VIN first, and we'll tell you what you have and what it costs.

Back with your VIN and coding · can’t be repaired? repair price back, minus shipping · 1-year warranty · rush 2–3 days +$100
