Ford · 2011-2019 · MK100
Ford Explorer (2011-2019) ABS module repair
Mail in your Ford Explorer (2011-2019) ABS module with our prepaid label. It comes back repaired and still coded to your VIN — or, if it is past repair, as a refurbished unit with your data cloned on, or with your repair price refunded minus shipping.
- Unit: MK100
- Stability control: depends on trim
- 28 sourced part numbers
- 3 fault codes
Known failure
The ABS module in the Ford Explorer (2011-2019)
The 2011-2019 Ford Explorer (2011-2019) uses this ABS unit: Continental ATE (2016-2019 per a rebuilder snippet) MK100 (2016-2019 Explorer, a rebuilder tag page snippet). source ↗ On our bench that puts it in the Continental MK100 family, alongside 5 other vehicle lines on this site.
Its ABS module appears under 28 part numbers in the sources we checked, starting with CB5Z-2C219-A (Ford catalog: 'Control Module', 2011 Explorer 3.5L; also a rebuilder's 2011-2015 list). source ↗ Different numbers usually separate model years, drivetrains and option packages — match the number on your own module label rather than the year alone. The control unit is mounted on the valve block. On many units it unbolts, so the brake lines stay on — send us a photo if you are not sure.
Ford Explorer (2011-2019) ABS module part numbers
Match the number printed on your module's label. Each number links to the page it was found on.
CB5Z-2C219-A
source ↗Ford catalog: 'Control Module', 2011 Explorer 3.5L; also a rebuilder's 2011-2015 list
CB5Z-2C219-C
source ↗Ford catalog: 'Control Module', 2011-2012 Explorer (2.0L/3.5L)
CB5Z-2C405-C
source ↗Ford catalog: 'Control Unit Assembly', 2011-2012 Explorer
CB5Z-2C215-A
source ↗Ford catalog: 'Modulator Valve', 2011-2012 Explorer
DB5Z-2C219-A
source ↗Ford catalog: 'Control Module', 2013 Explorer
DB5Z-2C219-B
source ↗Ford catalog: 'Control Module', 2013-2014 Explorer
DB5Z-2C219-C
source ↗Ford catalog: 'Control Module', 2013 Explorer
DB5Z-2C405-A
source ↗Ford catalog: 'Control Unit Assembly', 2013-2014 Explorer
DB5Z-2C215-A
source ↗Ford catalog: 'Modulator Valve', 2012-2014 Explorer
DB5Z-2C215-B
source ↗Ford catalog: 'Modulator Valve', 2014-2015 Explorer
EB5Z-2C219-A
source ↗Ford catalog: 'Control Module', 2014-2015 Explorer
FB5Z-2C219-A
source ↗Ford catalog: 'Control Module', 2016-2019 Explorer (2.3L/3.5L/3.7L)
Show all 28 part numbersShow fewer
FB5Z-2C215-A
source ↗Ford catalog: 'Modulator Valve', 2016-2019 Explorer
BB53-2C219-AD
source ↗A rebuilder: 2011-2015 Explorer control module (engineering number)
BB53-2C219-AE
source ↗A rebuilder: 2011-2015 Explorer control module
BB53-2C219-AF
source ↗A rebuilder: 2011-2015 Explorer control module
BB53-2C219-BF
source ↗A rebuilder: 2011-2015 Explorer control module
CB53-2C219-DD
source ↗A rebuilder: 2011-2015 Explorer control module
CB53-2C219-ED
source ↗A rebuilder: 2011-2015 Explorer control module
DB53-2C219-AC
source ↗A rebuilder: 2011-2015 Explorer control module
DB53-2C219-AD
source ↗A rebuilder: 2011-2015 Explorer control module
DB53-2C219-DD
source ↗A rebuilder: 2011-2015 Explorer control module
DB53-2C219-ED
source ↗A rebuilder: 2011-2015 Explorer control module
EB53-2C219-AA
source ↗A rebuilder: 2011-2015 Explorer control module
EB53-2C219-AB
source ↗A rebuilder: 2011-2015 Explorer control module
EB53-2C219-BA
source ↗A rebuilder: 2011-2015 Explorer control module
EB53-2C219-BB
source ↗A rebuilder: 2011-2015 Explorer control module
EB532C405AA
source ↗A rebuilder catalogue title 'EB532C405AA / 28526480333 - Ford EXPLORER - ABS' (ATE-style supplier no. 28.5264-8033.3; years not in snippet)
Reading the label · ATE / Continental Teves (supplier number, all brands)
Read as 10.0xxx-xxxx.x: control units 10.0960-/10.0961-/10.0926-/10.0948- with '.3', hydraulic units 10.0212-/10.0204-/10.0399- with '.4'. Often run together as 11 digits (10021200214 = 10.0212-0021.4 on the same a rebuilder.com page). source ↗
e.g. 10.0960-0818.3 · 10.0961-0820.3 · 10.0212-0044.4
Reading the label · Ford-style number (Jaguar / Land Rover, Ford era)
Prefix (4 chars: year letter/digit + vehicle code) + base + suffix. ABS/ESP bases seen on Jaguar/Land Rover units: 2C219, 2C353, 2C405, 14F447. a rebuilder's MK25 list has Jaguar-era examples (2W932C219BB, 4R832C219BD) but the same page also covers Ford/Lincoln, so those are format examples only. source ↗
e.g. BJ32-2C405-AG · GX53-2C353-AH · EX53-14F447-BC
Reading the label · Jaguar (pre-Ford numbering and later Jaguar numbers)
1995-2003 Jaguar ABS modules: three letters + '2210' + two-letter suffix (LNA/LNC/LNF/LJA/MNA 2210 xx), plus JLM + 5 digits on the 1995-1997 module. Later Jaguar part numbers: C2x / T2x + 4-5 digits (e.g. C2Z28243, T2R22161). source ↗
e.g. LNC2210AD · LNA 2210-AA · MNA 2210-AB
Our promise
Can’t be repaired? You don’t pay for a repair.
If the bench finds your module past repair, we stop and tell you before doing anything else. Then you choose:
- 1A replacement — a refurbished unit of the same family with your VIN, coding and configuration cloned onto it, from $950. You pay only the difference from what you already paid, and we confirm the amount with you first.
- 2Your module back — with the repair price refunded, minus shipping costs.
Either way, nothing that changes your price happens without your OK.
Refund stages in our terms →Other vehicles with the MK100
Same unit family, same bench process and the same starting price.
- 2015-2020 Audi A3 / S3 (8V)
- 2013-2019 Ford Escape (2013-2019)
- 2016-2021 Honda Civic (10th gen)
- 2018-2020 Jeep Wrangler (JL)
- 2009-2020 Volkswagen Tiguan (5N, first generation)
Ford Explorer (2011-2019) ABS module questions
Which ABS module is in the Ford Explorer (2011-2019)?
The source we cite lists it as: Continental ATE (2016-2019 per a rebuilder snippet) MK100 (2016-2019 Explorer, a rebuilder tag page snippet). We price and bench it as part of the Continental MK100 family. The exact unit is confirmed from your module label on arrival.
How much does ABS module repair cost for a Ford Explorer (2011-2019)?
Repair of your own module starts at $499; a replacement unit with your data cloned starts at $950. Return shipping starts at $29.95 and the label to us is prepaid.
My Ford Explorer (2011-2019) module number is not listed. Can you still repair it?
The 28 numbers above are the ones we could source, not every one that exists. Send us a photo of the label first, or order the repair and we confirm the unit before any work.
Ford Explorer (2011-2019) ABS light on? Fix the module you already own — from $499.
Look up your part number and order online — we email you a prepaid label to our lab. Or send us a photo of the label and your VIN first, and we'll tell you what you have and what it costs.
Back with your VIN and coding · can’t be repaired? repair price back, minus shipping · 1-year warranty · rush 2–3 days +$100
