Dodge · 2002-2008 · EBC325
Dodge Ram 1500 (DR) ABS module repair
Mail in your Dodge Ram 1500 (DR) ABS module with our prepaid label. It comes back repaired and still coded to your VIN — or, if it is past repair, as a refurbished unit with your data cloned on, or with your repair price refunded minus shipping.
- Unit: EBC325
- Stability control: depends on trim
- 43 sourced part numbers
- 6 fault codes
Known failure
The ABS module in the Dodge Ram 1500 (DR)
The 2002-2008 Dodge Ram 1500 (DR) uses this ABS unit: Kelsey-Hayes (2002-2005); TRW (2006-2008, see notes) Kelsey-Hayes 325 for 1998-2005 Ram 1500/2500/3500; TRW EBC-345 for 2006-2009 Ram 1500/2500/3500 4. The same unit covers the Ram 1500 (DR) and Ram 1500 SRT-10. On our bench that puts it in the Kelsey-Hayes EBC325 family, alongside 5 other vehicle lines on this site.
Its ABS module appears under 43 part numbers, starting with 5083096AA (Mopar ABS module, 2002 Dodge Ram 1500 3.7L/4.7L/5.9L). source ↗ Different numbers usually separate model years, drivetrains and option packages — match the number on your own module label rather than the year alone. Only the control module ships — it comes off the valve body on its own, so the brake lines stay on the vehicle.
Dodge Ram 1500 (DR) ABS module part numbers
Match the number printed on your module's label. Each number links to the page it was found on.
5083096AA
source ↗Mopar ABS module, 2002 Dodge Ram 1500 3.7L/4.7L/5.9L
5083096AC
source ↗Mopar 'Module-Anti-Lock Brakes; Control Module', 2002-2003 Ram 1500 3.7L/4.7L/5.9L; replaces 5083096AB
5080491AB
source ↗Mopar ABS module, 2002 Ram 1500 3.7L/4.7L/5.9L
52010032AF
source ↗Mopar ABS control module, 2002-2003 Ram 1500 3.7L/4.7L/5.9L; replaces 52010032AD, 52010032AE
5096311AA
source ↗Mopar ABS module, 2003 Ram 1500 5.7L
5083097AD
source ↗Mopar ABS module, 2003 Ram 1500 3.7L/4.7L/5.7L/5.9L; replaces 5083097AC and 5101759AA
5101759AA
source ↗2003 Ram 1500; replaced by 5083097AD
52010035AH
source ↗Mopar ABS pump/module, 2003 Ram 1500; replaced by 52010035AL
52110033AD
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit Anti-Lock Brake', 2003 Ram 1500 5.7L; replaced by 52110033AE
5103454AA
source ↗Mopar 'Module-Anti-Lock Brakes', 2003 Ram 1500 5.7L; replaced by 5103454AB
5134733AA
source ↗Mopar 'Module-Anti-Lock Brakes', 2004 Ram 1500 3.7L/4.7L
5134733AB
source ↗Mopar 'Module-Anti-Lock Brakes; Control Module', 2005 Ram 1500 3.7L/4.7L
Show all 43 part numbersShow fewer
5134527AA
source ↗Mopar 'Module-Anti-Lock Brakes', 2004 Ram 1500 SRT-10 8.3L
5127593AB
source ↗Mopar 'Module-Anti-Lock Brakes; Control Module', 2004-2005 Ram 1500 5.7L
5114536AB
source ↗Mopar ABS module, 2004-2005 Ram 1500 3.7L/4.7L
5114536AC
source ↗Mopar ABS control module, 2005 Ram 1500 3.7L/4.7L
5114537AB
source ↗Mopar ABS module, 2004 Ram 1500 5.7L
5114537AC
source ↗Mopar 'Module-Anti-Lock Brakes', 2005 Ram 1500 5.7L
5114537AD
source ↗Mopar 'Module-Anti-Lock Brakes; Control Module', 2005 Ram 1500 5.7L
52121406AA
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit Anti-Lock Brake', 2004 Ram 1500 3.7L/4.7L
52121406AC
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit Anti-Lock Brake', 2005 Ram 1500 3.7L/4.7L
52121407AA
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit Anti-Lock Brake', 2004 Ram 1500 5.7L
52121407AC
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit Anti-Lock Brake', 2005 Ram 1500 5.7L
52010035AK
source ↗Mopar ABS control module, 2004 Ram 1500 3.7L/4.7L; replaced by 52010035AL
52010035AN
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit; ABS Control Unit, Brake Line', 2005 Ram 1500 3.7L/4.7L
55366040AC
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit; ABS Control Unit, Brake Line', 2004-2005 Ram 1500 5.7L
5142862AB
source ↗Mopar 'Module-Anti-Lock Brakes; Control Module', 2005 Ram 1500 3.7L/4.7L
5142869AA
source ↗Mopar 'Module-Anti-Lock Brakes', 2005 Ram 1500 SRT-10 8.3L
5290922AA
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit', 2005 Ram 1500 SRT-10 8.3L
5175414AB
source ↗Mopar 'Module-Anti-Lock Brakes', 2006 Ram 1500 (incl. SRT-10)
5175414AD
source ↗Mopar ABS module, 2007 Ram 1500; replaced by 5175414AF
5175413AC
source ↗Mopar ABS module, 2006 Ram 1500 3.7L/4.7L/5.7L; replaced by 5175413AD
55366355AD
source ↗Mopar ABS control module, 2006 Ram 1500; replaced by 55366355AE
55366355AF
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit Anti-Lock Brake', 2007 Ram 1500
55366355AJ
source ↗Mopar ABS control module, 2008 Ram 1500; replaced by 5175414AF
55366222AE
source ↗Mopar ABS control module, 2006 Ram 1500; replaced by 55366222AH
68001469AC
source ↗Mopar ABS module, 2007 Ram 1500; replaced by 68001469AD
68031387AD
source ↗Mopar ABS module, 2008 Ram 1500; replaces 68031387AC
68031390AA
source ↗Mopar 'Module-Anti-Lock Brake System; Control Module', 2008 Ram 1500
55398729AF
source ↗Mopar 'Module-Anti-Lock Brake; Control Unit; ABS Control Unit, Control Module', 2008 Ram 1500
55366224AE
55366224AI
68048345AB
Mopar ties 68048345AA to 2009 Ram 2500
Reading the label · Mopar (Chrysler / Dodge / Jeep / Ram) - current 68xxxxxx style
Eight digits followed by a two-letter revision suffix, e.g. 68259556AD. AA is the original release and the suffix advances AB, AC... As the part is revised. The 68 prefix is described by americanoemparts.com as 'Stellantis-era (post-2009)'; note that t source ↗
e.g. 68259556AD · 68067457AA · 68438389AB
Reading the label · Mopar (Chrysler / Dodge / Jeep / Ram) - legacy 5xxxxxx / 4xx
Older Chrysler numbers are a 7- or 8-digit numeric string plus a two-letter revision suffix (e.g. 5083285AA). A leading zero is only a catalog formatting prefix: 5083285AA and 05083285AA are the same part. source ↗
e.g. 52126282AC · 05179771AA
Reading the label · Mopar - older suffix-less numbers (1990s modules)
Some 1990s Chrysler ABS parts are catalogued with a bare 8-digit number and no two-letter revision suffix, e.g. 56026812 and 52004508 (1994-1997 Ram 1500 RWAL module / HCU in the Mopar catalog). '56027271' for 1997-2000 Wrangler TJ, '56041821' fo source ↗
e.g. 56026812 · 52004508 · 56027271
ABS fault codes on the Dodge Ram 1500 (DR)
Our promise
Can’t be repaired? You don’t pay for a repair.
If the bench finds your module past repair, we stop and tell you before doing anything else. Then you choose:
- 1A replacement — a refurbished unit of the same family with your VIN, coding and configuration cloned onto it, from $950. You pay only the difference from what you already paid, and we confirm the amount with you first.
- 2Your module back — with the repair price refunded, minus shipping costs.
Either way, nothing that changes your price happens without your OK.
Refund stages in our terms →Other vehicles with the EBC325
Same unit family, same bench process and the same starting price.
- 1999-2006 Chevrolet Silverado 1500 / 2500 (GMT800)
- 1998-2005 Dodge Ram 1500/2500/3500 (BR/BE, DR/DH)
- 2003-2009 Dodge Ram 2500
- 2000-2004 Ford F-150 (1997-2003 body, incl. 2004 F-150 Heritage)
- 2000-2005 Ford F-250 / F-350 Super Duty
Dodge Ram 1500 (DR) ABS module questions
Which ABS module is in the Dodge Ram 1500 (DR)?
It uses this unit: Kelsey-Hayes (2002-2005); TRW (2006-2008, see notes) Kelsey-Hayes 325 for 1998-2005 Ram 1500/2500/3500; TRW EBC-345 for 2006-2009 Ram 1500/2500/3500 4. We price and bench it as part of the Kelsey-Hayes EBC325 family. The exact unit is confirmed from your module label on arrival.
How much does ABS module repair cost for a Dodge Ram 1500 (DR)?
Repair of your own module starts at $325; a replacement unit with your data cloned starts at $950. Return shipping starts at $29.95 and the label to us is prepaid.
My Dodge Ram 1500 (DR) module number is not listed. Can you still repair it?
The 43 numbers above are the ones we could source, not every one that exists. Send us a photo of the label first, or order the repair and we confirm the unit before any work.
Dodge Ram 1500 (DR) ABS light on? Fix the module you already own — from $325.
Look up your part number and order online — we email you a prepaid label to our lab. Or send us a photo of the label and your VIN first, and we'll tell you what you have and what it costs.
Back with your VIN and coding · can’t be repaired? repair price back, minus shipping · 1-year warranty · rush 2–3 days +$100
